Machine Drawing and Computer Graphics

•  5th Edition - 320 pages.  •

  • Simple and Lucid Explanation on Principles of Drawing.

  • Includes Examples of Production Drawings.

  • Covers AutoCad with insight to Layers, Blocks, Scripts and Slide Files.

  • Introduction to Programming in AutoLISP including advanced features such as Entity and File Handling.

  • Includes the new features of AutoCAD 2005 and VLISP.

  • Suitable for Students and Design Offices.

  • Fifth Revised Edition with New Programs.

  • Free Enclosures with the book - 7 Drawing Sheets and 1 AutoCAD Quick Reference Sheet

    • Downloads

  • Readme MDCG.pdf
    •         Contains the Instructions for the programs.

  • A2005.zip
    •         Zip File - containing 28 AutoCad 2005 Drawing files.

  • SCRIPT.zip
    •         Zip File - containing 33 AutoCad Script and Slide files.

  • LISP.zip
    •         Zip File - containing 73 LISP program files.
